Switchcraft 3 Position Toggle Switch Exact Replacement For Gibson Les Paul #12010X Gold (1)

Switchcraft? 3 Position Toggle Switch Exact Replacement For Gibson? Les Paul? #12010XThis is the exact Switchcraft? straight toggle switch with 3/16 in. threaded bushing length as used by Gibson? on the Les Paul? model guitars. Many manufacturers have adopted using this switch on similar two pickup instruments where the thread does not pass through a thicker top than the bushing length. The addition of deep toggle switch nut may be used to extend bushing length to securely fasten it to an instrument with a carved top. Switchcraft #12010X.Electrical:Contact Ratings: Fine silver contacts rated at 3A, 300W maximum AC non-inductive load standard.Leakage Resistance: 1,000 MW or greaterDielectric Strength: 250 VDCMaterials:Frame: Steel, platedBushing and Shaft: Copper alloy, platedSprings: Copper alloyKnob: Molded thermoplasticMounting Hardware: Knurled copper alloy locknut T10711, suppliedInsulation: Rigid plastic spacers with plastic tubing through stack. Rigid plastic and/or thermoplastic lifters. Thermoplastic cam on actuator end
